| Place of Origin: | China |
|---|---|
| Brand Name: | Screw Press Dehydrator |
| Certification: | CE |
| Model Number: | DL303 |
| Minimum Order Quantity: | 1 set |
| Price: | effective solutions |
| Packaging Details: | Standard wooden box |
| Delivery Time: | 20-30 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 40 sets per month |
| Product Name: | Screw Press Dehydrator | DS Capacity: | 90-150 Kg/h |
|---|---|---|---|
| Material: | Stainless Steel SUS304 SUS316 | Sludge Treatmnt Capacity: | 3-45 M3/hr |
| Application: | Sludge Dewatering | Function: | Reduce Cleaning Water Consumption |
Multidisc sludge dewatering screw press is integrated with sludge flocculation tank which efficiently mixes the input sludge with the optimal dose of flocculation.
This flocculated sludge then enters the screw body which in the initial stage has more open area to dewater the separated water faster.
As screw rotates at a rpm which is set to give optimum output carries the dewatered concentrated sludge forward towards the end.
As screw is been gradually increasing making the valley / volume available for the sludge narrow towards the outlet so that flocculated sludge that is concentrated by gravity filtration is further dewatered by compression.
DAGYEE Multi-disc screw press dehydrators can cope up with a wide range of sludge concentrations from 0.2% to 10%, and also stably can dewater sludge that has high oil content.
Screw Press Dehydrator Features
Screw Press Dehydrator Technical Table
| Model | DL303 |
| DS capacity kg/h | 90--150 kg/h |
| Sludge capacity m3/h(2-50g/L) | 3-45 |
| Spiral diameter mm | ￠310*3 |
| Discharge Distance mm | 495 |
| Size L*W*H mm | 3605*1690*1600 |
| Net.Kg | 1520 |
| Run Kg | 3080 |
| Power Kw | 1.86 |
| Washing Q L/h | 120 |
Screw Press Dehydrator Application
