2 Phase Horizontal Drilling Mud Juice Decanter Centrifuge Optimization Palm Oil Sludge Separation

2 Phase Decanter Centrifuges Description

The machine starts and speeds up automatically.When the proper working condition are met and the revolving drum reaches the feeding speed,the feeding valve opens and allows suspension which will be separated to enter into the product compartment of the spiral feeder through the feeding pipe.After the preliminary speed-up,the suspension passes the outlet of compartment and into the drum.Because of centrifugal force,the suspension in the drum is quickly divided into two phases;the heavier solid phase deposits to the inner wall of the drum and driven by the differential gear which results in the non-cynchronous movement between the spiral feeder and the drum.the solid phase will be transferred into the small end for further dehydration and finally discharged through solid phase outlet.The separated liquid flows out though the big end or will be driven out by centrifugal pump.

2 Phase Decanter Centrifuges Model

2 Phase Decanter Centrifuges Technical

All contact parts can be made by SS304/SS316L/Duplex Steel 2205 Automatic adjustment of differential speed via VFD,Siemens PLC Spiral : Surfacing welding tungsten carbide grinding

Two motor drive
Approximately 80 to 90% of the oil is recovered
Low labor costs due to continuous and automatic operation
Highest g-force for higher solids output
Belts for both primary motor and secondary
NSK/SKF Bearing

2 Phase Decanter Centrifuges Features

Low noise, its vibration intensity is less than 4.5, and the running noise of the machine is less than 85dB (A)
High Speed up to 3600RPM & Variable Speed by frequency converter

The main body of the decanter centrifuge made from stainless stee: SS304/SS316/Titanium Alloy

The screw propeller made from stainless steel (SS304/SS316) protected by Tungsten carbide alloy or Ceramic

Solids discharge stainless steel protected by high-chromium iron

Solids Liquid separation system package available

Germany FAG/SKF brand bearings

Eletrical Components: SIEMENS/Schneider/ABB
All the seals of the machine are imported , adopting the Taiwan TTK brand

2 Phase Decanter Centrifuges Application

City tap water, domestic sludge dewatering;

Oil drilling mud dewatering;

Sludge Oil Recovery;

Refinery sludge concentrated dehydration;

Distiller ‘s grains dehydration;

Paper, printing and dyeing wastewater separation;

Medical sludge dewatering;

Soy protein dehydration;

Plant oil clarification and separation;

Cosmetic clarification and separation;

Bleaching powder separation.
