| Place of Origin: | Jiangsu.China |
|---|---|
| Brand Name: | Cartridge Filter Housing |
| Certification: | CE |
| Model Number: | DYG-10-40 inch |
| Minimum Order Quantity: | 1PCS |
| Price: | Negotiable |
| Packaging Details: | Wooden box, standard container, Customers can specify requirements |
| Delivery Time: | 15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200SET |
| Condition: | New | Material: | 304 316L |
|---|---|---|---|
| Weight: | 150-1500 | Size: | 10-40" |
| MOQ: | 1 Set | Capacity: | 1-65m3/hr |
| Application: | Filtration | Warranty: | 1 Year |
| Highlight: | 40 inch ss cartridge filter housing,316l ss cartridge filter housing,304 ss cartridge filter housing |
||
Cartridge filter, also known as security filters, generally set before the pressure vessel to remove the tiny particles whose turbidity above 1 degree, to meet the requirements of the follow-up process of water; sometimes, it is also set at the end of the entire water system to prevent small particles (such as broken resin) into the finished water.
| Model | DYG-10-40‘’ |
| Material | SUS304 SUS316 |
| Applicable Filter Cartridges | Industrial PP Filter Cartridges String Wound Filter Cartridges Stainless Steel Filter Cartridges |
| Filtration accuracy | 0.1-200UM |
| Connection Type | With a clamp /BSP female |
| Surface treatment | Mirror reflection |
| Applicable field | Water treatment Beveragepharmaceutical Electronics Chemical Petroleum Paint Glue |
| Housing Dimensions (mm) | Ø300*1450 |
| Max. Flow Rate (m3 /h) | 10 |
| Max. Operating Conditions (bar/°C) | 10/150 |
| Inlet/Outlet (flange) | 1 1/2'' |
| Length of Filter Cartridge | 40'' |
| No. of Filter Cartridges | 10 |
| Max. Cartridge Outside Diameter(mm) | Ø60 |
Commonly used wound filter and meltblown filter
Wound filter (also known as honeycomb filter), there are two types: one is polyp
ropylene fiber - polypropylene skeleton filtration, the maximum temperature 60 ℃; the other is cotton fiber - stainless steel frame filter, the maximum temperature 120 ℃.
Raw material of meltblown filter is polypropylene, the maximum operating temperature is 60 ℃. Sophisticated filters can remove suspended solids, colloidal substances and some fine particulate matter and so on.
1.High filtration precision, uniform pore size filter.
2.Small filtration resistance, flux, interception capability, long service life.
3.Filter is clean and no second pollution to the filter media.
4.It also can filter acid, alkali and other chemical agents.
5.High-intensity,heat-resistant,deformation resistance.
6.Low price, low running costs, easy to clean, filter can be replaced.
1.Food industry:fine filter of space water, mineral water,beverages, liquor clarification and filtration process.
2. Pharmaceutical industry: sterile water, oral, infusion and injection water treatment.
3. Electronics industry: water preparation semiconductors, instruments, picture tubes and other production plants, wash water filtration bar.
4. Chemical industry: organic solvents, esters, alcohols, acids, alkalis and other chemicals, oils purification.
5. Oil industry: oil field water injection preparation and so on.
6. Environmental protection, electroplating wastewater, printing waste, pharmaceutical waste and other industrial wastewater treatment.
7. Seawater, brackish water desalination water treatment, hotels, apartments water treatment.
8. Precision filter is often used as security filter for electrodialysis, ion exchange, security filters reverse osmosis devices.
