| Place of Origin: | Jiangsu.China |
|---|---|
| Brand Name: | Dagyee Multi 40 Cartridge Filter Housings |
| Certification: | SGS |
| Model Number: | DYG-40-40 inch |
| Minimum Order Quantity: | 1PCS |
| Price: | Negotiable |
| Packaging Details: | Wooden box, standard container, Customers can specify requirements |
| Delivery Time: | 15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 500SET |
| Condition: | New Multi 40 Cartridge Filter Housings | Material: | Sanitary 316L |
|---|---|---|---|
| Weight: | 150 | Size: | 40 Inch |
| MOQ: | 1 Set | Capacity: | 40m3/hr |
| Application: | Filtration,water Treatment | Warranty: | 1 Year |
| Highlight: | 40 inch cartridge filter housing ss316,multi cartridge filter housing ss316,water treatment cartridge filter housing ss316 |
||
Adopt to mechanical polishing,material liquid touch area Ra<0.4um,absolute health level of polishing , can select all series electrolytic polishing.
- It can increase the vent hole and dreain hole diameter Effectively , and can connect 8mm pipe.
- Drain valve independent from the exhaust valve thread joint sets and pagoda,operating is more convenient.
- Adopt to hing segmented clamp ,20% higher than an ordinary card hoop pressure,maximum pressure up to 1.0Mpa.
- Supporting feet adopt to strengthening threaded,not easy sliding teeth;Install a adjustable nut at the bottom of the leg , filter's height can be adjustment .
| Model | DYG-40-40‘’ |
| Material | SUS304 SUS316 |
| Applicable Filter Cartridges | Industrial PP Filter Cartridges String Wound Filter Cartridges Stainless Steel Filter Cartridges |
| Filtration accuracy | 0.1-200UM |
| Connection Type | With a clamp /BSP female |
| Surface treatment | Mirror reflection |
| Housing Dimensions (mm) | Ø550*1450 |
| Max. Flow Rate (m3 /h) | 40 |
| Max. Operating Conditions (bar/°C) | 10/150 |
| Inlet/Outlet (flange) | 1 1/2''/OEM |
| Length of Filter Cartridge | 40'' |
| No. of Filter Cartridges | 40 |
| Max. Cartridge Outside Diameter(mm) | Ø60 |
Material: SUS304L, SUS316L
1.Seal type: O-rings and flat gasket
2. Sealing material: nitrile rubber(chemitum), silicone, fluorine rubber, usually use silicon rubber seal
3. Filter interface: the threaded, clamp(hoop), GB, HG, DIN, ANSI, JIS standard flange
4. Filtration accuracy: 1μm - 100 μm
5. Body material: SS304/SS 316
1.Inlet & outlet size is 1/2", 3/4". 1" for easy installation.
2. Working pressure 8kg/0.8Mpa, 10kg/1Mpa is supported.
3. Use the tap water pressure to provide power, no power consumption.
4. Wall-mounted, counter-top, very simple installation.
5. It is suitable for using in the water mater switch, for the pre filtration system and RO system protection.
6. Resistance to strong acid and alkali.
7. Low cost, it fits different kind of filter elements.
1.High filtration precision, uniform pore size filter.
2.Small filtration resistance, flux, interception capability, long service life.
3.Filter is clean and no second pollution to the filter media.
4.It also can filter acid, alkali and other chemical agents.
5.High-intensity,heat-resistant,deformation resistance.
6.Low price, low running costs, easy to clean, filter can be replaced.
Water Treatment, RO system;
·Pharmaceuticals, API, Biologics;
·Food and Beverage, Wine, Beer, Mineral Water, Distillation Equipment;
·Paints, Inks Plating Solutions;
·Process Chemicals and Electronics Industry ;
