| Place of Origin: | Jiangsu.China |
|---|---|
| Brand Name: | Dagyee |
| Certification: | CE |
| Model Number: | DYG-5-40'' |
| Minimum Order Quantity: | 1PCS |
| Price: | Negotiable |
| Packaging Details: | Wooden box, standard container, Customers can specify requirements |
| Delivery Time: | 15 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200SET |
| Condition: | New | Product Name: | Cartridge Water Filter Housing |
|---|---|---|---|
| Raw Material: | Stainless Steel Boards | Filtration Accuracy: | 0.1-200UM |
| Type: | With A Clamp | Diameter: | 65 Mm |
| Max. Flow Rate: | 10 M3 /h | Applicable Field: | Chemical |
Dagyee DYG-5-40'' 5 Stainless Steel Cartridges Filter Housings 40'' With Clamp Precision Water
DAGYEE Cartridge Housing
Multi-barrel stainless steel liquid filter housing is a high-quality solution for high-volume filtration. Our multi-cartridge housing can accommodate 5 to 22 standard 30-inch and 40-inch filter elements, and the liquid filtration flow rate is up to 65 m3/hr.
Commercial and industrial filter housing liquid containers are ideal for chemical systems, commercial RO and membrane water treatment systems for pre-filtration, high-purity water, post-filtration, food and beverage, industrial facilities, etc.
We always have a large stock of stainless steel liquid housings for commercial and industrial use. Most of the models shown are available from stock immediately.
5 Cartridges Filter Housings 40'' With Clamp Specification
| Model | DYG-5-40'' |
|
Material |
SUS304, SUS316 |
|
Applicable Filter Cartridges |
Industrial PP;String Wound;304;316 |
|
Filtration accuracy |
0.1-200UM |
|
Connection Type |
With a clamp /BSP female |
|
Surface treatment |
Mirror reflection |
|
Housing Dimensions (mm) |
Ø219mm*1390mm |
|
Max. Flow Rate (m3 /h) |
10 |
|
Max. Operating Conditions (bar/°C) |
6/150 |
|
Inlet/Outlet (BSP female) |
2'' |
|
Length of Filter Cartridge |
40'' |
|
No. of Filter Cartridges |
5 |
|
Max. Cartridge Outside Diameter (mm) |
Ø65 |
DAGYEE Cartridge Housing Feature
Precision filter housing with clampopening.
The body open the way for quick opening hoop (or quick opening flange), to facilitate the efficient filter replacement and cleaning.
Compact structure, small size, improved V-shaped hoop quick opening, the stress tests, the pressure without any distortion and leakage after 0.6MPA.
Cartridge filter uses stainless steel as material,with electrochemical polishing or matte finishing out appearance. Also PP is available.
DAGYEE Cartridge Housing Application
Food industry:fine filter of space water, mineral water,beverages, liquor clarification and filtration process.
Pharmaceutical industry: sterile water, oral, infusion and injection water treatment.
Electronics industry: water preparation semiconductors, instruments, picture tubes and other production plants, wash water filtration bar.
Chemical industry: organic solvents, esters, alcohols, acids, alkalis and other chemicals, oils purification.
Oil industry: oil field water injection preparation and so on.
Environmental protection, electroplating wastewater, printing waste, pharmaceutical waste and other industrial wastewater treatment.
Seawater, brackish water desalination water treatment, hotels, apartments water treatment.
Precision filter is often used as security filter for electrodialysis, ion exchange, security filters reverse osmosis devices.
DAGYEE Cartridge Housing Removal
Suspended matter
Algae
Impurities
Fine particles
