Q Screen Wastewater Stationary Dewaters Fine Particle Sieve Self Cleaning Products

Static Screen Wastewater Description

DAGYEE provides reliable performance in liquid/solid separations for municipal and industrial applications, especially when sieving fibrous and non-oily solids. There are no moving parts, motors or complicated connections. Liquid/solid separation screens are economical and simple to operate.

Static screen is mainly used for the pretreatment of wastewater treatment,which can effectively remove most of the suspended solids in the wastewater and reduce the processing load of subsequent processes, also used for solid-liquid separation and recovery of useful substances in induatrial wastewater treatment. It is an excellent non-powered device for filtering or recovering solid or colloidal substances such as suspended solids, floating matter and sediment.

Static Screen Wastewater Works

Influent pumped into the inflow chamber through the inlet of the pipe. As the water level rises, it will flow under the wage weir and the pivoting baffle. Liquids and solids flow through the screen, and Liquids falls through the screen, while gravity and more screening push the captured solids toward the discharge point. The wastewater passes through the filter enters distribution chamber and flows through the outlet tube. The drip-proof assembly at the bottom of the filter directs excess water to the waste chamber. When the solids reach the bottom of the screen, they slide into the container, conveyor or other suitable receiving equipment. Dagyee offers a variety of rear screen and dewatering equipment. To assemble the most cost-effective screening system. Welcome to consult.

Static Screen Wastewater Model

Static Screen Wastewater Feature

No energy
High separation efficiency of slag and water, ensuring normal operation of follow-up equipment
Smooth drainage, not easy to block
Simple structure and long service life
Easy to move and clean
Material and screen plate, which can be customized according to requirements

Static Screen Wastewater Application

Industrial wastewater treatment plants;
Textile;
Paper;
Slaughterhouse;
Food and plastic recycling wastewater treatment plants.
